SVR-3200

SVR-1680C

SVR-1660C

SVR-1645

SVR-960C

SVR-945

SVR-480

Display

Video

lnputs

32 Composite
video 0.5…2 Vpp,
75 ohm automatic
termination

16 Composite
video 0.5…2 Vpp,
75 ohm automatic
termination

9 Composite video
0.5…2 Vpp,
75 ohm automatic
termination

4 Composite
video 0.5…2 Vpp,
75 ohmautomatic
termination

Resolution

NTSC: 704×480
PAL: 704×576

Live

Frame Rate

NTSC: 960fps
PAL: 800fps

NTSC: 480fps
PAL: 400fps

NTSC: 270fps
PAL: 225fps

NTSC: 120fps
PAL: 100fps

Resolution

NTSC: 704×480
PAL: 704×576

Multi Screen
Display

1/4/9/10/16
(To view 32 channels 2× monitors are required)

1/4/9

1/4

Performance

Compression

MPEG-4

Recording

Record Rate
(Up to, fps)

NTSC:
480@704×480
960@704×240
960@352×240
PAL:
400@704×576
800@704×288
800@352×288

NTSC:
480@704×480
480@704×240
480@352×240
PAL:
400@704×576
400@704×288
400@352×288

NTSC:
120@704×480
240@704×240
480@352×240
PAL:
100@704×576
200@704×288
400@352×288

NTSC:
120@704×480
240@704×240
270@352×240
PAL:
100@704×576
200@704×288
225@352×288

NTSC:
120fps@704×480
120fps@704×240
120fps@352×240
PAL:
100fps@704×576
100fps@704×288
100fps@352×288

Mode

Manual, Schedule, Event, Emergency

Overwrite
Modes

Continuous

Pre-alarm

Up to 5sec

Post-alarm

Up to 60sec

Search &
Playback

Search Mode

Date/Time, Event, Calendar, Thumbnail, Bookmark, Text (Exclusive viewer)

Playback
Function

REW, FWD, Frame advance (Control keys and jog shuttle)

REW, FWD,
Frame advance
(Control keys)

Network

Transmission
Speed

Up to 16Mbps

Up to 9Mbps

Bandwidth
Control

Automatic

Multi Stream

MPEG-4 (Dual Stream) / JPEG

MPEG-4 / JPEG

Max. Remote
Users

10 Simultaneously

Protocol
Support

TCP/IP, DHCP, DNS, DDNS, HTTP, ARP, ICMP and NTP

Monitoring

CMS Software (SNM-128S/P), Built-in web server

Storage

Maximum
Capacity

Up to 16TB using external storage option

Up to 8TB using
external storage option

Internal HDD

Up to 4SATA HDDs

Up to 2 SATA HDDs

External HDD

Up to 2 expansion bay

Up to 1 expansion bay

DVD Writer
(Backup)

DVD-R/CD-R

N/A

USB (Back up)

2 External USB ports

File Format
(Back up)

BMP, AVI, Proprietary format /JPEG (Exclusive viewer)

Security

Password
Protection

10 User level

Data
Authentication

Watermark

Interface

Monitors

VGA

Analog RGB 800×600,1024×768,1280×1024 resolution (SVR-3200 : 2 VGA)

Main
Composite

BNC, 1 Vp-p, 75 ohm, Multi-screen,
Menu, Playback

1 BNC, 1 Vp-p, 75 ohm, Multi-screen,
Menu, Playback

Spot
Composite

3 BNC, 1 Vp-p, 75 ohm,
Multi-screen, Menu

1 BNC, 1 Vp-p, 75 ohm,
Single-screen, Menu

Loop Outputs

N/A

16 Composite
video
1 Vpp, 75 ohm

9 Composite
video
1 Vpp, 75 ohm

4 Composite
video
1 Vpp, 75 ohm

Audio

Inputs

16 Line in, 30K ohm

9 Line in, 30K ohm

N/A

Output

1 Line, 100K ohm

Compression

ADPCM

Sampling Rate

16KHZ

Alarm

Inputs

Terminal 16 inputs, NO/NC

Terminal 9 inputs, NO/NC

Terminal 4 inputs

Outputs

Terminal 4 relay
outputs, NO/NC

Terminal 2 relay
outputs, NO/NC

Remote
Notification

Notification via e-mail

Connections

Ethernet

RJ-45 10/100 Base-T

Serial Interface

RS-232C

PTZ Control
Interface

RS-485/422

RS-485

Via coax cable (SVR-1680C/1660C/960C)

PTZ Keyboard

RS-485, Max. signal voltage ±12V

USB

USB 2.0

eSATA

2 External SATA ports

1 External SATA port

Application
Support

ATM/POS, Mouse, Remote controller

Dome
Protocols

Supported
PTZ Cameras

Samsung Techwin, Pelco D, Pelco P, Pelco Coaxitron, Panasonic, Bosch, SEC

General

Electrical

Input Voltage

100…240V AC ±10%, 50/60HZ, Autoranging

Power
Consumption

Max. 66W (With 1× HDD)
Max. 130W (With 4× HDD)

Max. 66W (With 1× HDD)
Max. 88W (With 2× HDD)

Environmental

Operating
Temperature

+5°C…+40°C (+32°F…+104°F)

Operating
Humidity

0%…60%RH

Mechanical

Dimensions
(W×H×D) (mm)

445×88×412

300×88×332

350×88×401

Weight

Approx. 11Kg
(24.25 lb, 4× Hard Disks)

Approx. 8.6Kg
(18.96 lb,
2× Hard Disks)

Approx. 5Kg
(11.02 lb)

Approx. 5.6kg
(12.34 lb)

Rack Mount Kit

For mounting one unit in an EIA 19 inch rack

Language

English, Korean, Spanish, French, German, Italian, Portuguese, Polish, Russian, Turkish, Japanese,
Czech, Serbian, Swedish, Rumanian, Danish
