| DISPLAY |
|
| Screen Size Diagonal (inches) |
49.9 |
| Aspect Ratio |
16:9 |
| Number of Pixels |
786,432 (1,024 x 768) |
| Panel |
G15 Progressive HD Plasma |
| HDTV Display Capability (1080p, 1080i, 720p) |
yes |
| Aspect Control |
4:3, Just, Zoom, Full, H-fill |
| PICTURE |
|
| Shades of Gradation |
6,144 equivalent |
| Panel Drive |
600 Hz Sub-Field Drive |
| 24p Playback (3:2)/24p Smooth Film |
yes/ - |
| AUDIO |
|
| 3D Real Sound |
yes |
| Number of Speakers |
2 |
| Audio Output |
20 W |
| Surround Sound |
AV Surround |
| JACKS |
|
| Integrated ATSC Tuner |
yes |
| HDMI Input |
null / 2 |
| Support Feature |
Audio Return Channel (Input 2) |
| SD Card |
yes (SDHC) |
| USB2.0 |
1 |
| Analog Audio Input ( for HDMI/DVI) |
yes |
| Composite Video Input shared with Component |
RCA x 1 |
| Audio Input (for Composite Video) |
RCA x 1 |
| Component Video Input (Y, PB, PR) shared with Composite |
RCA x 1 |
| Audio Input (for Component Video) |
RCA x 1 |
| Digital Audio Output (Optical) |
1 |
| FEATURES |
|
| Media Player |
null / yes (SD Card/USB) |
| Support Format |
AVCHD/SD-VIDEO/MP4/MKV, MP3/AAC, JPEG |
| Game Mode |
yes |
| Pixel Orbiter (Anti-Image Retention) |
yes |
| Trilingual Menu (English/Spanish/French) |
yes |
| Built-In Closed Caption Decoder |
yes |
| Off - Timers |
yes |
| GENERAL |
|
| Power Supply |
AC 120 V, 60Hz |
| Receiving System |
ATSC/QAM/NTSC |
| Dimensions with stand |
|
| Height [inches (mm)] |
29.9" (757 mm) |
| Width [inches (mm)] |
46.7" (1,184 mm) |
| Depth [inches (mm)] |
10.5" (266 mm) |
| Dimensions W/O stand |
|
| Height [inches (mm)] |
28.2" (716 mm) |
| Width [inches (mm)] |
46.7" (1,184 mm) |
| Depth [inches (mm)] |
Max.: 3.2" (81 mm); General: 2.5" (63 mm) |
| Weight with stand [lbs (kg)] |
49.6 lbs. ( 22.5 kg) |
| Weight W/O stand [lbs (kg)] |
46.3 lbs. (21.0 kg) |
| Carton Dimensions |
|
| Height [inches (mm)] |
32.6" (828 mm) |
| Width [inches (mm)] |
53.0" (1,344 mm) |
| Depth [inches (mm)] |
10.0" (252 mm) |
| Gross Weight [lbs (kg)] |
64.0 lbs. (29 kg) |
| Operating Temperature |
32°F - 104°F (0°C - 40°C) |
| Safety Standard |
US: UL60065/FCC Part15, CANADA: CSA C22.2/IC BETS-7 |
| Optional Wall-mounting Bracket Model Numbers |
TY-WK4P1RW |
