| PLAYABLE DISCS |
| BD-ROM |
| BD-RE/ BD-RE DL (Ver.3) |
| BD-R/ BD-R DL (Ver.2) |
| DVD |
| DVD-R/ DVD-R DL/ DVD-RW |
| +R/ +R DL/ +RW |
| CD, CD-R/ -RW |
| |
| AUDIO SYSTEM |
| Dolby® Digital Plus/ Dolby® TrueHD |
yes Decode(5.1ch) and Bitstream Output*2 |
| DTS™-HD Master Audio Essential/ DTS™-HD High Resolution Audio |
yes Decode and Bitstream Output*2 |
| |
| SD MEMORY CARD |
| Slot |
yes |
| Compatible Media |
SD/ SDHC/ SDXC |
| Playback |
| |
| USB |
| Slot (Front, Rear) |
yes (For Playback, - ) |
| USB Standard |
USB 2.0 High Speed |
| Playback |
| |
| HIGH QUALITY PICTURE |
| Built-in 4K (Ultra HD) Up-scaling |
- |
| Adaptive Chroma Processing |
- |
| 2D-3D Conversion |
yes (BD/ DVD/ CD/ SD Memory Card/ VOD/ USB/ NAS) |
| 3D Effect Controller |
yes (BD/ DVD/ CD/ SD Memory Card/ VOD/ USB/ NAS) |
| Full HD Up Sampling |
yes |
| 1080/24p Playback 1 |
yes*4 |
| Deep Color |
yes |
| x.v.Color |
yes*5 |
| |
| HIGH QUALITY SOUND |
| TWIN HDMI |
- |
| High Quality Network Audio Playback |
yes |
| Pure Audio on HDMI |
- |
| High Clarity Sound Plus |
- |
| Digital Tube Sound |
- |
| Audio D/A Converter |
- |
| Analog 7.1ch Output |
- |
| 96kHz Surround Re-Master 2 |
- *6 |
| |
| EASY OPERATION |
| Miracast™ |
yes*7 |
| Web Browser |
yes |
| Touch Pad Remote |
- |
| Smartphone Remote Control |
- *8*9 |
| Multi-User Mode/ Stylish GUI/ Wallpaper |
yes |
| VIERA Link™ (HDAVI Control 5) 3 |
- |
| |
| NETWORKING |
| VIERA Connect™ |
yes*10 |
| IP VOD |
- |
| Wireless LAN System |
yes (Built-in) |
| DLNA (DMP&DMR) Function |
yes |
| External HDD Playback |
yes*12 |
| Network Drive Access |
yes |
| BD-Live™ |
yes*13 |
| |
| TERMINAL |
| HDMI Output |
yes |
| Video Output |
- |
| Optical Output |
yes |
| Coaxial Output |
- |
| Analog Audio Output |
- |
| LAN (Ethernet) Terminal |
yes (for DLNA, BD-Live™*13, VIERA Connect™*10 and Firmware Update) |
| |
| OTHERS |
| Video System |
NTSC |
| Audio S/N |
- |
| Dynamic Range |
- |
| Power Supply 4 |
AC 120V, 60Hz |
| Power Consumption |
| |
| DIMENSIONS, WEIGHT |
| Dimensions (W x H x D) [Approx.] |
16-15/16 x 1-1/2 x 7-1/16 inch *15 |
| Weight [Approx.] |
3.08 lbs. |
| |
| Further Specifications |
| NOTE |
*1 Discs recorded and finalized on recording devices. / *2 HDMI connection required. / *3 Only Full-HD and SD 24p content can be up-converted for 4K2K resolution. For 4K2K playback a TV with same resolution is required. / *4 For BD-ROM/ BD-R, DVD and VOD via HDMI in BBT01 and BDT500. For BD-ROM/ BD-R/ DVD via HDMI in BDT330, BDT230, BD89 and BD79. / *5 This function is effective only when reproducing AVCHD data recorded with x.v.Color technology. The function cannot be used with BD-ROM or DVD-ROM discs. HDMI connection is required. x.v.Color is a registered trademark. / *6 CD sampling is done at 88.2 kHz. MP3 data can be re-mastered only on CD. / *7 Compatible with AndroidTM devices, Ver. 4.2 and above and Miracast certified. For information on whether the smartphone, etc. supports Miracast, contact the manufacturer of the device. / *8 Requires the device with the App installed and the player to be connected to the same home network. / *9 App is available on the App Store℠. App is available on Google Play™. / *10 Requires broadband Internet service. / *11 With the purchase of Wireless LAN Adaptor DY-WL5. / "*12 The external HDD with capacities of 2TB or less in processing NTFS/ FAT32 data is supported. Playback is not possible with some external hard disk drives. / The Blu-ray DiscTM Player with two USB terminals can read from an external HDD only when the HDD is connected to the USB terminal on the right side. / " / *13 To enjoy content, you will need to insert a SD card in BBT01 and BDT500 or USB flash drive in BDT330, BDT230, BD89 and BD79 (1GB or more of free space/ sold separately). Requires broadband Internet service. / *14 Using included AC adaptor. / *15 Excluding the projecting parts and the pedestal. / Playability may vary depending on the contents, discs and quality of the recording. For content recorded for your personal use. / Specifications are subject to change without notice. Weight and dimensions are approximate. |
| WARNING |
WARNING: The recording and playback of content on this or any other device may require permission from the owner of the copyright or other such rights in that content. Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. It is your responsibility to ensure that your use of this or any other device complies with applicable copyright legislation in your country. Please refer to that legislation for more information on the relevant laws and regulations involved or contact the owner of the rights in the content you wish to record or playback. |
| Playability may vary depending on the contents, discs and quality of the recording. For content recorded for your personal use. |
|
| Specifications are subject to change without notice. Weight and dimensions are approximate. |
|
